Saw blade KSB-WL 280 GT
HW, 280 x 2,8 x 30mm (11 in.), T15-5, AT/FT, Wood Rip Cut
Ref. no.:
092598
- Group-toothed tooth geometry
- Reduced cutting forces for a longer battery life
- Optimum cutting quality
Technical data
| Diameter | 280 mm |
| Diameter | 11 1/32 in |
| Weight | 0,775 kg |
| Weight | 1.709 lbs |
| Group tooth pattern | 3 x 5 |
| Cutting width | 2,8 mm |
| Cutting width | 1/8 in |
| Body thickness | 1,8 mm |
| Body thickness | 1/16 in |
| Arbor | 30 mm |
| Arbor | 1 3/16 in |
| Tooth geometry | WZ/FZ |
| Tooth count | 15 |
Product details
The new saw blades with group-toothed tooth pitch and innovative cutting geometries are specially adapted to the application areas of Mafell saws.
The new generation of tooth pitch noticeably improves the cutting quality, reduces power consumption and significantly improves chip transport.
In addition, the edge quality of saw cuts at right angles to the fibre direction is improved and a faster sawing progress is clearly noticeable.
Applications
- For longitudinal cuts
- Solid wood panels, laminated wood panels
Advantages
- The unique combination of a narrow kerf and optimised carbide alloy ensures a longer battery life and significantly longer material service life.
Usage
The irregular tooth pitch is instrumental in achieving the new quality of cut. Evidence shows both a reduction in cutting force and an improvement in cutting quality.
Alongside new tooth geometry, the innovative arrangement of the teeth achieves unsurpassed cutting quality.
