Door Lock Mortiser SKS 130

: The chain bars are maintenance-free and do not need to be re-greased.

: Mortising lengths of 78 mm (3 1/16 in.) and mortising widths of 16 mm (5/8 in.) are possible with one cut. Wider and longer slots can also be made to the exact millimetre by following up with the SKS 130.

: No longer a problem: quick, precise lock mortising is now possible on a mounted door.

: Two special mortising chains in opposite directions ensure tear-free work and optimum chip flow.

Door Lock Mortiser SKS 130 in carrying case with 18 mm chain set Door Lock Mortiser

The chain bars are maintenance-free and do not need to be re-greased.

Mortising lengths of 78 mm (3 1/16 in.) and mortising widths of 16 mm (5/8 in.) are possible with one cut. Wider and longer slots can also be made to the exact millimetre by following up with the SKS 130.

No longer a problem: quick, precise lock mortising is now possible on a mounted door.

Two special mortising chains in opposite directions ensure tear-free work and optimum chip flow.

By viewing the video, you agree
that your data is transferred to YouTube and that
you have read the privacy policy.

Order number: 915502
Delivery specification
- 2 Chain bars cpl.; Ref. No. 091000
- 2 Sprockets; Ref. No. 091002
- 1 Allen key 5 mm; Ref. No. 093278
- 2 Mortising chains; Ref. No. 091003
- 1 Mains cable 4 m (13.1 ft); Ref. No. 087323
- in carrying case

Mortising depth	130 mm
Mortising width	14, 16, 18 mm
Mortising length	78 mm
Stroke/working travel	175 mm
Nominal No. of strokes – no load	5770 1/min
Nominal power input	1600 W
Weight	10,6 kg
Universal motor	230 V / 50 Hz

Cutting mortises for lock cases (installation of safety locks) Compatible materials include...

Cutting mortises for lock cases (installation of safety locks)
Compatible materials include doors made of wood and wood-based materials, solid wood

Two special mortising chains in opposite directions - for tear-free work and optimum chip flow....

Two special mortising chains in opposite directions - for tear-free work and optimum chip flow.
Handy, ergonomic, compact construction – for on-site work on mounted doors.
Two special mortising chains in opposite directions – for tear-free work and optimum chip flow.

The SKS 130 – the world´s first portable special machine for mortising door locks. The security...

The SKS 130 – the world´s first portable special machine for mortising door locks.
The security needs of many house and apartment owners have increased considerably, so that more and more security locks are being fitted.
At 1600 watts (2.1 hp), the SKS 130 cuts door locks of all sizes - completely tear-free!
The SKS 130 is clamped onto a large surface of the door. Due to the Pertinax/rubber surface of the clamping device, the door surface remains protected, whether mounted on site or in the workshop.

Operating instructions
